How to Make a Remote-Control Rocket Launcher



If you want a simple, homemade launcher that can be triggered with an RF remote, this project shows an easy and safe way to make one at home. The launcher uses a heated nichrome wire to launch a small rocket (model rocket / paper rocket) from a PVC tube mounted on a wooden stand. Follow the steps carefully and respect all safety precautions.

Materials



 How it Works

The RF remote activates a receiver that supplies current from the battery to the nichrome wire. When the wire heats up rapidly, it generates the thrust or releases a latch that allows the rocket to launch from the PVC tube. The wooden stand keeps the launcher stable and aimed away from people and flammable objects.

Circuit Diagram

Remote control rocket Launcher

Step-by-step Build

  1. Prepare the launcher tube and stand

    • Cut a piece of PVC pipe to the desired length. Smooth any rough edges.

    • Build or cut a wooden stand or cradle that holds the tube at a slight upward angle (about 30–45°) and keeps it stable.

  2. Mount the nichrome wire

    • Shape a short length of nichrome wire into a loop or strip and secure it across the mouth or inside the top section of the PVC where it will interact with the rocket (or act as a release point). Use heat-resistant tape or ceramic supports so the wire doesn’t touch the PVC directly.

  3. Wire the RF receiver and battery

    • Connect the RF relay/receiver output to the nichrome wire circuit so the receiver switches the battery current to the nichrome.

    • Make sure wiring is insulated and connections are secure. Use a proper transistor or MOSFET if the receiver cannot directly handle the current required by the nichrome wire.

  4. Test electronics without a rocket

    • With the launcher pointed at a safe, open area, test the remote so the nichrome heats up when activated. Confirm the receiver and battery connections behave as expected. Do not install a rocket during this test.

  5. Load and launch

    • Place a lightweight rocket into the PVC launcher. Make sure the rocket fits freely and there are no obstructions.

    • Step back to a safe distance, aim away from people/animals/buildings, then press the remote to trigger the launch.

    • Remote control rocket

Safety Precautions –

  • Use this device only outdoors in a clear open area away from people, animals, buildings, dry grass, and other flammable materials.

  • Nichrome wires get extremely hot — avoid touching them and ensure nothing flammable is nearby.

  • Use proper battery protection (fuses, correct wiring) to avoid short circuits or thermal runaway, especially with lithium batteries.

  • Never leave the launcher unattended while armed.

  • Ensure your local laws and regulations permit launching model rockets or similar devices — follow all legal and safety guidelines.

  • Wear safety glasses and keep a fire extinguisher or water source nearby during tests.

  • If you’re unsure about wiring high-current circuits, consult an experienced electronics hobbyist or professional.

Tips & Improvements

  • Use a dedicated switching transistor or MOSFET with a flyback diode (if needed) instead of routing high current through the RF receiver contacts. This increases reliability and safety.

  • Create a removable battery pack and a safe arming/disarming switch to prevent accidental trigger.

  • Consider adding a simple latch mechanism released by the heated wire, so the wire itself doesn’t need to be the main launch force — this reduces required current and heat.

  • For repeatable launches, make a small rail or guide inside the tube to keep the rocket aligned.
